Power Required	50-90 hp	Drive Type	Gearbox with belt
Minimum Power	50 hp	Number of Belts	5
Working Width	87 in	Belt Type	AV 17*1245
Overall Width	96 in	Drive Blet Tensioner	Yes, bolts tightened
Variable Cutting Height	0-3 in	Deck Material	0.2 in
Horicontal Etending Distance	13 in	Side Plate Material	0.3 in
With Rear Open Door	2 pcs rear open door	PTO Shaft RPM	540 rpm
Blade Number	20	Driveline Shaft Length	39-50 in
Blade Type	Hammer	Spline End:   PTO Shaft Spline	1.375"  z6
Blade Weight	2.7 lbs	3-Point Hitch	CAT 2
Blade Material	Cast steel	Tractor Mount	Three-point hitch
Rotor Bearing	SKF Bearing	Gearbox 0il Type	85W/90
Rotor Diameter	6 in	Dimensions (L x W x H)	96x46x37 in
Rotor Swing Diameter	16 in	Packing Size	97x38x28 in
Rotor Thickness	0.3 in	Finsh	Durable Powder Coated finish
Rotor Shaft Speed	2082 rpm	Warranty	1 year
Blade Speed	31.5 mph	Net Weight	1221 lbs
Rotor Rotation	Clockwise	Gross Weight	1389 lbs

WARNlNG: This product can expose you to chemicals including engine exhaust (including diesel engine exhaust when equipped),lead and lead compounds, mineral oils, soots, phthalates, and carbon monoxide which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
Certain specification(s) are based on engineering calculations and are not actual measurements. Specification(s) are provided for comparison purposes only and are subject to change without notice. Specification(s)  for your individual equipment will vary based on normal variations in design, manufacturing, operating conditions, and other factors.
