Power Required	75-110 Hp	Belt Adjustment	Manual Mechanical Tension
Working Width	78 in	Working Efficiency450 cu.ft./Hr.	500 cu.ft./Hr.
Overall Width	90in	PTO Shaft Speed	540 rpm
Blade Ground Clearance	0.5in-2.5in	Deck Thickness	0.16 in
Max. Cutting Diameter	2in	Side Plate Thickness	0.25 in
Offset Distance from The Center (Maximum)	127in	Driveline Shaft Length	T6-LF-65  with Shear Bolt ; 65in-77in
Tilt-Up Angle	90°	Spline End	1.375in  Z6
Tilt-Down Angle	40°	3-Point Hitch	CAT 2
Number Of Blades	26	Gearbox 0il Type	85W-90
Number of Belts	4	Finsh	Powder Coating
Blade Type	Hammer	Warranty	1 Year
Blade Weight	2.6 lbs	Shipping Box	96 X 39 X 31in
Blade Material	Cast Steel	Weight (N.W./G.W.)	1645/1711 lbs

WARNlNG: This product can expose you to chemicals including engine exhaust (including diesel engine exhaust when equipped),lead and lead compounds, mineral oils, soots, phthalates, and carbon monoxide which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
Certain specification(s) are based on engineering calculations and are not actual measurements. Specification(s) are provided for comparison purposes only and are subject to change without notice. Specification(s)  for your individual equipment will vary based on normal variations in design, manufacturing, operating conditions, and other factors.
