Engine Power Required	15-35HP	Drive Type	Belt drive
Working Width	60in	Number of Belts	3
Overall Width	65in	Belt Size	V Belt 13 X 1041
Blade Ground Clearance	0.6in-1.8in	Drive Belt Tensioner	Yes
Max. Cutting Diameter	Depends On The Type Of Grass	Deck Thickness	0.16in
Number Of Blades	24	Side Plate Thickness	0.24in
Blade Type	Hammer	PTO Shaft RPM	540 RPM
Size Of Blades	3.5 x 3 x 1.6in	Driveline Shaft Length	T5-LF-31 with shear bolt; 31- 43in
Blade Weight	0.8lbs	Spline End	1.375in  z6
Blade （Tines）Material	Cast Steel	Tractor Mount	Reversible
Rotor Bearing	SKF bearing	Gearbox Oil Type	85W-90
Rotor Diameter	3in	Dimensions (L x W x H)	65 x 30 x 28in
Rotor Swing Diameter	11in	Finish	Powder Coat Paint  Galvanized Steel
Rotor Thickness	0.3in	Warranty	1 year
Rotor Shaft Speed	2958 rpm	Weight (N.W./G.W.)	406/503 lbs
Blade Speed	142 ft/s

WARNlNG: This product can expose you to chemicals including engine exhaust (including diesel engine exhaust when equipped),lead and lead compounds, mineral oils, soots, phthalates, and carbon monoxide which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
Certain specification(s) are based on engineering calculations and are not actual measurements. Specification(s) are provided for comparison purposes only and are subject to change without notice. Specification(s)  for your individual equipment will vary based on normal variations in design, manufacturing, operating conditions, and other factors.
