Engine Power Required	70-110 Hp	Belt Adjustment	Bolt Tightening
Working Width	72 in	Working Efficiency450 cu.ft./Hr.	450 cu.ft./Hr.
Overall Width	86 in	PTO Shaft Speed	540 rpm
Blade Ground Clearance	0.5 in-2.6 in	Deck Thickness	2 in
Max. Cutting Diameter	Depends On The Type Of Grass	Side Plate Thickness	0.25 in
Offset Distance from The Center (Maximum)	111 in	Driveline Shaft Length	T6-LF-73  With Shear Bolt ; 73in-126in
Tilt-Up Angle	90°	Spline End	1.375in  Z6
Tilt-Down Angle	55°	3-Point Hitch	CAT 2
Number Of Blades	16	Gearbox 0il Type	85W-90
Number of Belts	4	Finish	Powder Coating
Blade Type	Hammer	Warranty	1 Year
Blade Weight	2.6 lbs	Shipping Box	89 X 39 X 31in
Blade Material	Cast Steel	Weight (N.W./G.W.)	1429 /1587 lbs

WARNlNG: This product can expose you to chemicals including engine exhaust (including diesel engine exhaust when equipped),lead and lead compounds, mineral oils, soots, phthalates, and carbon monoxide which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
Certain specification(s) are based on engineering calculations and are not actual measurements. Specification(s) are provided for comparison purposes only and are subject to change without notice. Specification(s)  for your individual equipment will vary based on normal variations in design, manufacturing, operating conditions, and other factors.
