Engine	DUCAR DH420E	Blades Type	Double Edge Blade
Engine Type	Single Cylinder, 4 Stroke, Air-Cooled, OHV	Discharge Chute	360 Degree Rotating
Displacement	420 cc; 15 HP	Emergency Stop	Stop Button
Start	E-Start	Feed Chute Opening Method	Hinge
Battery	12V 20Ah Lead-Acid	Discharge Chute Opening Method	Hinge
Belt	2 x V-Belts	Towing	Tow Bar With 2 in Coupler
Belts Material	Kevlar	Tire	16 x 8.00-7 O.D. Road Tires
Clutch	Centrifugal Clutch	Wheelbase	46 in
Cutting Method	Drum	Package Method	Plywood Case
Chipping Dia.	5 in	Weight (N.W./G.W.)	441 / 498 lbs
Roller	13.8 in	Product Size (L*W*H)	102 x 46 x 56 in
Reduction Ratio	20:1	Packing Size (L*W*H)	36 x 31 x 49 in
Knives Nos.	2 x Blade; 1 x Anvil	Machine Warranty	2 Years
Knives Material	A8 (5Cr8MoVSi )	Engine Warranty	2 Years



WARNlNG: This product can expose you to chemicals including engine exhaust (including diesel engine exhaust when equipped),lead and lead compounds, mineral oils, soots, phthalates, and carbon monoxide which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
Certain specification(s) are based on engineering calculations and are not actual measurements. Specification(s) are provided for comparison purposes only and are subject to change without notice. Specification(s)  for your individual equipment will vary based on normal variations in design, manufacturing, operating conditions, and other factors.
